Phase Sequence Meter SM-852B
Original price was: 3,500.00৳ .3,250.00৳ Current price is: 3,250.00৳ .
Phase Sequence Meter Victor – 850A
Original price was: 2,800.00৳ .2,650.00৳ Current price is: 2,650.00৳ .
Description
Specification:
- Model: VC850
- Operation Voltage: 200V ~ 480V AC, three phase
- Limit Support Voltage: 2000 V/min
- Operating Frequency Range: 20 Hz ~ 400 Hz
- Time Limit for Continuous Use:
- 60 minutes maximum at 200V AC
- 4 minutes maximum at 480V AC
- Test Leads: Double insulation
- Length of test leads: approx. 1 meter long (3.3 feet)
- Withstand Voltage: 4000v for 1 minute
- Operating Temperature: -10 ~ 60 °C (14 ~ 140 °F)
- Item dimensions: approx. 85 (L) x 59 (W) x 23 (D) mm (3.2′ x 2.4′ x 0.9′ inch)
- Item weight: approx. 200g (7.05 oz)
- General characteristic
- 1 x Phase Sequence Rotation Indicator
- This meter specializes in phase sequence and phase failure examine of three phase simple alternating current; Check the presence of open phase and also the phase sequence by LED and buzzer at the same time. LED and buzzer indicate positive phase sequence, negative phase sequence and lacking phase. based on IEC-348 safety class II, best quality with low price.
